Description
xPhoenix Inverter 24/375 230V VE.Direct IEC
The Victron Phoenix Inverter 24/375 is a compact DC-to-AC inverter designed for 24V battery systems, delivering 375VA of continuous 230V AC output. It is suited to off-grid installations, marine and vehicle applications, and backup power setups where a reliable, lightweight inverter is required. The VE.Direct interface allows direct communication with compatible Victron monitoring devices and displays.
Key Features
- 375VA continuous output at 230V AC from a 24V DC battery bank.
- Pure sine wave output, suitable for sensitive electronics and motor loads.
- VE.Direct port for connection to Victron monitoring devices such as the Color Control GX, MPPT displays and the VictronConnect app via a VE.Direct to USB or Bluetooth dongle.
- IEC AC output socket for direct appliance connection without additional wiring.
- Low idle power consumption, reducing unnecessary battery drain in standby conditions.
- Built-in protections including low battery voltage shutdown, over-temperature and overload protection.
- Compact and lightweight form factor at 3.25 kg, practical for space-constrained installations.
Product Overview
The Phoenix 24/375 converts 24V DC from a battery bank into a stable 230V AC pure sine wave output. Pure sine wave output is important because it replicates grid-quality power, making the inverter compatible with inductive loads such as small motors and fans, as well as sensitive electronics that would be damaged or perform poorly on a modified sine wave. At 375VA, this unit is sized for lighter loads: phone and laptop chargers, LED lighting circuits, small power tools, and similar equipment.
The VE.Direct interface is a key practical feature for professional installations. It allows the inverter to be integrated into a Victron system monitored via a GX device or the VictronConnect app, giving installers and end users visibility of inverter status, load and fault conditions without additional hardware. The IEC output socket means the unit can be deployed quickly in applications where a direct plug-in connection is appropriate, such as a van conversion, boat or small off-grid cabin.
The inverter includes automatic protection against low battery voltage, overload and over-temperature. These protections are not user-adjustable but are factory-set to appropriate thresholds for 24V lead-acid and lithium battery chemistries. Installers should verify that the battery bank capacity and charge source are correctly sized for the intended load profile.
Technical Specifications
| Specification | Value |
| SKU | PIN241371100 |
| Nominal DC Input Voltage | 24V |
| Continuous Output Power | 375VA |
| AC Output Voltage | 230V AC |
| Output Waveform | Pure sine wave |
| Communication Interface | VE.Direct |
| AC Output Connector | IEC socket |
| Weight | 3.25 kg |
| GTIN | 8719076055969 |
Applications
- Off-grid cabins and remote buildings requiring 230V AC from a 24V battery bank.
- Marine installations powering small AC loads from a 24V house battery system.
- Campervan and motorhome conversions where a compact, lightweight inverter is needed.
- Backup power for small office or telecoms equipment during grid outages.
- Mobile or portable power setups integrated into a Victron VE.Direct monitoring system.
What Is Included
- Victron Phoenix Inverter 24/375 230V VE.Direct IEC unit
Installation Notes
This inverter operates at 24V DC and must be connected to a correctly fused DC supply. DC wiring should be sized appropriately for the peak current draw. Installation should be carried out by a qualified electrician or experienced system integrator. This unit is not grid-connected and does not require G98 or G99 compliance. For integration into a wider Victron system, a VE.Direct cable (sold separately) is required to connect to a GX device or VictronConnect Bluetooth dongle. Ensure adequate ventilation around the unit to prevent thermal shutdown under sustained load.
