xVictron MultiPlus 12/3000/120-50 230V VE.Bus Inverter Charger
The Victron MultiPlus 12/3000/120-50 is a combined inverter and battery charger in a single unit, designed for 12V battery systems requiring 3000VA of AC output at 230V. It is suited to off-grid installations, marine and vehicle applications, and backup power systems where reliable DC-to-AC conversion and mains charging are both required.
Key Features
- 3000VA continuous inverter output at 230V AC from a 12V DC battery bank.
- 120A battery charger built in, with adaptive charge algorithm to suit a range of battery chemistries including flooded, AGM and gel.
- 50A AC passthrough allows shore power or generator input to supply connected loads directly while simultaneously charging the battery.
- PowerControl and PowerAssist functions prevent overloading a limited AC source by supplementing it with battery power when demand exceeds supply.
- VE.Bus communication interface enables system integration, parallel operation and three-phase configuration with compatible Victron equipment.
- Transfer switch with a typical switchover time of 20 milliseconds, fast enough for most computers and sensitive electronics.
- Programmable relay and two-signal BMS connection support for lithium battery systems.
Product Overview
The MultiPlus combines a true sine wave inverter with a multi-stage battery charger. In inverter mode, it converts 12V DC from a battery bank into 230V AC at 3000VA continuous output. The built-in 120A charger uses an adaptive algorithm that adjusts the charge profile based on battery behaviour, which helps extend battery service life across different chemistries. The 50A AC input passthrough means that when a mains or generator supply is available, loads are fed directly from that source while the charger tops up the batteries.
PowerAssist is a particularly practical feature for installations where the available AC source is limited, such as a shore power connection with a fixed amperage limit or a small generator. When load demand exceeds what the AC source can supply, the MultiPlus draws the deficit from the battery bank rather than tripping the supply. This allows a smaller, more economical generator to be used without risk of overload.
VE.Bus connectivity allows multiple MultiPlus units to be configured in parallel for increased current capacity, or in split-phase and three-phase arrangements. The interface also supports integration with Victron system monitoring and control products, including the Color Control GX and Venus GX. Configuration and firmware updates are handled via the VE.Bus interface using Victron's VEConfigure software.
Technical Specifications
| Parameter | Value |
| SKU | PMP123021010 |
| DC Input Voltage (Nominal) | 12V |
| Inverter Output Power | 3000VA |
| AC Output Voltage | 230V AC |
| Battery Charger Output | 120A |
| AC Input (Passthrough) | 50A |
| AC Output Waveform | True sine wave |
| Communication Interface | VE.Bus |
| Weight | 18.85 kg |
| GTIN | 8719076023951 |
Applications
- Off-grid cabins, lodges and remote buildings requiring 230V AC power from a 12V battery bank.
- Marine vessels with 12V DC systems needing shore power integration and onboard AC supply.
- Motorhomes, coaches and large campervans with high AC load requirements.
- Backup power systems for critical equipment where fast transfer from mains to battery is required.
- Generator-assisted off-grid systems where PowerAssist reduces the required generator size.
- Parallel or three-phase Victron system builds using VE.Bus for expanded capacity.
What Is Included
- 1x Victron MultiPlus 12/3000/120-50 230V VE.Bus inverter charger unit.
Installation Notes
The MultiPlus 12/3000/120-50 handles significant DC current at 12V and must be installed by a qualified electrician or accredited installer. DC cable sizing, fusing and battery connection must be rated appropriately for the current involved. For any grid-connected or shore-power applications, wiring must comply with BS 7671 (IET Wiring Regulations). Lithium battery installations require correct BMS integration via the two-signal BMS port. VE.Bus configuration should be carried out using Victron's VEConfigure software before commissioning. This unit is not suitable for direct grid-tied export without additional equipment and compliance assessment.
