xVictron Inverter 24V 2500VA 230V Smart
The Victron Inverter 24/2500 230V Smart is a pure sine wave inverter designed for off-grid and backup power applications running from a 24V battery bank. It delivers up to 2,400W of continuous power at 25°C and includes built-in Bluetooth for wireless monitoring and configuration via the VictronConnect app.
Key Features
- 2,400W continuous output at 25°C, with a 4,000W peak power rating for motor and compressor starting loads
- Built-in Bluetooth and VE.Direct port for full configuration and monitoring via VictronConnect
- Dynamic Low DC Shutdown adjusts the low battery cut-off threshold based on load, protecting the battery bank without unnecessary shutdowns
- ECO mode reduces no-load consumption to 1.6W by switching the inverter off when no load is detected and restarting when demand returns
- Programmable relay rated at 230V/4A AC or 4A DC (up to 35VDC) for external signalling or load control
- Remote on/off terminal allows integration with external control systems or a simple switch
- Comprehensive protection: output short-circuit, overload, high and low battery voltage, over-temperature, AC voltage on output, and excessive DC ripple
- Rated IP21 and tested to EN-IEC 60335-1, with ECE R10-5 automotive directive compliance for mobile applications
Product Overview
The 24/2500 Smart operates from a 24V nominal battery bank with a DC input range of 18.6V to 34V. At 25°C it delivers 2,400W continuously, derated to 2,200W at 40°C and 1,500W at 65°C. The 94% maximum efficiency and 10W no-load draw (1.6W in ECO mode) make it practical for installations where the inverter spends significant time on standby, such as off-grid cabins, vehicles and backup systems.
Bluetooth connectivity is built in, so no additional interface hardware is needed for commissioning or monitoring. VE.Direct provides a wired data connection to compatible Victron devices including the Color Control GX and other GX-series monitors. All parameters, including ECO mode thresholds and low battery shutdown behaviour, are configurable through VictronConnect.
The steel enclosure measures 509 x 219 x 125mm and weighs 13kg. Battery connections use M8 bolts and AC connections use screw terminals, both suited to permanent fixed wiring. The operating temperature range of -40°C to 65°C covers demanding environments including cold-climate off-grid sites and vehicle installations.
Technical Specifications
| Parameter | Value |
| Nominal Battery Voltage | 24V |
| DC Input Voltage Range | 18.6V to 34V |
| AC Output Voltage | 230V / 50Hz |
| Continuous Power at 25°C | 2,400W |
| Continuous Power at 40°C | 2,200W |
| Continuous Power at 65°C | 1,500W |
| Peak Power Rating | 4,000W |
| Maximum Efficiency | 94% |
| No-Load Power Consumption | 10W |
| ECO Mode Consumption | 1.6W |
| ECO Mode Threshold | Adjustable |
| Dynamic Low DC Shutdown | Yes |
| Communication | Bluetooth, VE.Direct |
| Remote On/Off Terminal | Yes (screw terminal, 2-pole) |
| Programmable Relay | 230V/4A AC; 4A up to 35VDC; 1A up to 60VDC |
| Battery Connection | M8 bolts |
| AC Connection | Screw terminals |
| Protection Category | IP21 |
| Operating Temperature | -40°C to 65°C |
| Maximum Humidity | 95% |
| Safety Standard | EN-IEC 60335-1 |
| EMC Standards | EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
| Automotive Directive | ECE R10-5 |
| Enclosure Material | Steel (Blue RAL 5012 / Black RAL 9017) |
| Dimensions (H x W x D) | 509 x 219 x 125mm |
| Weight | 13kg |
| SKU | PIN242251000 |
Applications
- Off-grid cabins and rural properties running from 24V lead-acid or lithium battery banks
- Vehicle and marine installations requiring ECE R10-5 compliant inverters
- Backup power systems where standby efficiency is a priority
- Mobile off-grid setups such as expedition vehicles, motorhomes and working vans
- Solar off-grid systems integrated with Victron MPPT charge controllers and GX monitoring devices
What Is Included
- Victron Inverter 24/2500 230V Smart unit
Installation Notes
This inverter should be installed by a qualified electrician familiar with DC battery systems and off-grid AC wiring. Battery cables must be correctly rated and fused close to the battery terminals. The IP21 rating provides protection against vertical dripping water only; the unit must be installed in a dry, ventilated enclosure or compartment away from direct moisture exposure. For any installation forming part of a grid-connected or generator-backed system, ensure compliance with current UK wiring regulations and relevant network operator requirements.
