Description
xVictron Inverter 12/500 230V VE.Direct SCHUKO | PIN121501200
The Victron Inverter 12/500 is a compact 12V DC to 230V AC pure sine wave inverter with a 500VA continuous output rating. It is aimed at mobile, marine, and small off-grid installations where a reliable AC supply is needed from a 12V battery bank. The SCHUKO output socket makes it ready to use with standard European plugs, and the VE.Direct port allows direct communication with Victron monitoring equipment.
Key Features
- 500VA continuous output at 230V AC from a 12V DC battery source, suitable for powering small appliances and electronics.
- Pure sine wave output, compatible with sensitive equipment including motor-driven appliances, medical devices, and audio equipment.
- VE.Direct communication port for connection to Victron monitoring devices such as the Color Control GX, Cerbo GX, or a PC via VE.Direct to USB interface.
- SCHUKO output socket fitted as standard, ready for direct use with European-standard plugs without an adaptor.
- Built-in protections covering low battery voltage shutdown, high battery voltage shutdown, overload, short circuit, and over-temperature.
- PowerControl function limits AC output draw to protect the battery bank from excessive discharge.
- Compact and lightweight form factor at 4.1 kg, suitable for installation in confined spaces on vehicles, boats, or in small off-grid enclosures.
Product Overview
The 12/500 sits at the entry point of Victron's VE.Direct inverter range. At 500VA, it covers loads such as laptops, LED lighting circuits, small power tools, and low-wattage kitchen appliances. The pure sine wave output is important here: many switch-mode power supplies and motor-driven loads that tolerate a modified sine wave will still run more efficiently and with less heat on a pure sine wave, and some equipment will not function correctly on anything else.
The VE.Direct port is a key differentiator from basic inverters at this price point. It allows the unit to be integrated into a Victron system, reporting real-time data including AC output power, battery voltage, and alarm states to a GX device or directly to VictronConnect via a compatible interface. This makes it a practical choice for installers building monitored off-grid or vehicle systems where visibility of power consumption matters.
Protection thresholds are factory-set to suit standard lead-acid and AGM battery chemistries. Low-voltage shutdown prevents deep discharge damage to the battery bank. The over-temperature protection will reduce output or shut the unit down if the internal temperature exceeds safe limits, which is relevant in poorly ventilated installations. Adequate ventilation clearance around the unit should always be maintained.
Technical Specifications
| Parameter | Value |
| SKU | PIN121501200 |
| DC Input Voltage | 12V |
| Continuous Output Power | 500VA / 430W |
| AC Output Voltage | 230V AC |
| Output Waveform | Pure sine wave |
| Output Socket | SCHUKO (Type F) |
| Communication | VE.Direct |
| Weight | 4.1 kg |
| GTIN | 8719076045212 |
| Protections | Low/high battery voltage, overload, short circuit, over-temperature |
Applications
- Campervans and motorhomes requiring a 230V AC supply from a 12V leisure battery.
- Marine installations on small vessels needing AC power for navigation equipment or domestic appliances.
- Small off-grid cabins or garden buildings with a 12V battery system.
- Vehicle-based work setups where tools or laptop chargers require a mains-voltage supply.
- Backup power for low-wattage critical loads during short-term mains outages.
What Is Included
- Victron Inverter 12/500 230V VE.Direct SCHUKO unit
- DC connection cables (refer to Victron documentation for cable sizing requirements)
- Documentation and quick-start guide
Installation Notes
This inverter connects directly to a 12V DC battery bank. DC cable sizing and fusing must follow Victron's published guidelines for the 12/500 to ensure safe operation and to avoid voltage drop that will reduce output performance. The unit should be mounted in a dry, ventilated location away from direct heat sources. Although this inverter is not a grid-tied device and does not require G98 or G99 notification, any installation on a vessel or vehicle should comply with applicable wiring standards (BS EN ISO 13297 for marine, or BS 7671 for fixed installations). Installation by a qualified electrician or experienced marine/vehicle electrical engineer is recommended.
